Harden® Two Shaft Shredder TS Series (Single Drive) - Medium Duty
- Model
- TS612
Product review
Description
Harden® TS series are medium-duty Double shaft shredder. TS series
equip a single motor and gearbox. A set of transmission gear drives two shafts
rotating together, TS series are compact but with a powerful core, strong shaft
and blades and various operating protection.
TS series are
economical, batch produced with well workmanship. Each process, such as heat
treatment, hardness testing, and structural flaw detection, is strict to ensure
quality.
Features of Harden® Two Shaft Shredder
Stable
Quality | Wear-Resistant | Never Fracture
Professional
Design of Cutting Chamber
Stable
Operation | Internal Stress Decomposition | Strong Loading Capacity
Patented
Spline Shafts and Coupings
Quick
Maintenance | High Bearing Capacity
Model |
TS303 |
TS506 | TS508 |
TS612 |
Motor Power (KW) |
7.5 |
15 | 22/30 |
45 |
Rotating
Speed (RPM) | 18 | 24 | 14-32 | 15 |
Knife Thickness/Mesh Size (mm) |
10/33 |
20/60 | 28/86 |
30/60 |
Size of Cutting Chamber (AxB)(mm) |
330*360 |
500x600 | 860*500 |
1200*650 |
Machine Dimensions (LxWxH)(mm) | 1520*730*1350 | 2550x1300x2600 2550x1390x2900(with feeder) | 2650*1300*2630 2650*1900*2900(with feeder) | 3100*1900*2600 3200*2900*4000（with feeder） |
Capacity (Ton/Hour) | 1~2 | 3-6 | 6~10 | 10~15 |
